100W Hi-Fi Mono MOSFET Audio Amplifier Board – 2SC5200 & 2SA1943 Transistor-Based
Specifications
- Transistor Configuration: 2SC5200 (NPN) & 2SA1943 (PNP)
- Output Power: Up to 100W
- Power Supply Requirement: Dual AC supply of 24-0-24V with 5 A current capacity
- Speaker Compatibility: Supports 4Ω and 8Ω speakers
- Amplifier Class: Class AB
- Cooling Mechanism: Integrated heatsink for efficient heat dissipation
- Protection Features: Speaker protection circuit to prevent DC offset damage
SKU: 100W-HI-FI-5074
MRP RS.630.00
Rs.499.00 (Include Tax)
Perfectly Done
100W Hi-Fi Mono MOSFET Audio Amplifier Board – 2SC5200 & 2SA1943 Transistor-Based
This high-performance amplifier board employs the robust 2SC5200 and 2SA1943 transistors, renowned for their high power handling and linearity. Designed for audiophiles and DIY enthusiasts, it delivers clear and powerful audio output, making it ideal for home theater systems, custom speaker setups, and educational electronics projects. The board's design ensures minimal distortion and efficient power handling, providing an immersive listening experience
Features
- High Output Power: Delivers up to 100W, suitable for driving large speakers
- Robust Transistors: Employs 2SC5200 and 2SA1943 for reliable performance
- Versatile Power Input: Operates with a dual DC supply ranging from ±24-0-24 v
- Comprehensive Protection: Built-in speaker protection circuit to safeguard against DC offset
- Efficient Cooling: Equipped with a heatsink to maintain optimal operating temperatures
